| DMX512 ISOLATION AMPLIFERS AND SPLITTERS |
| Doug Fleenor Design's DMX512 isolators and splitters are considered some of the best products available for the
distribution of lighting control signals. Isolators are used to eliminate ground loops and to provide protection from electrical storms,
mis-connections, and equipment failures. Splitters are distribution products that provide many outputs from one input to distribute DMX512
to multiple locations such as stage left, stage right, first electric, and dimmer room. With the exception of our Inline Isolator, all
Doug Fleenor Design isolators and splitters may be used as line amplifiers to boost the signal from as little as 0.2 volts to full DMX output
levels. Portable, rack, and wall mount units are available. |
|
| Model: |
Description |
MSRP |
DATA SHEET |
PHOTOS |
DRAWINGS |
| DINTAP |
DIN-rail mounted DMX512 optical isolator |
$444.00 |
PDF |
N/A |
N/A |
| 121 |
Single input, single output for isolation and boosting |
$556.00 |
PDF |
 |
PDF DWG |
| 121D |
Two inputs, two outputs for two universes |
$742.00 |
PDF |
|
DWG |
| 121Q |
Four inputs, four outputs for 4 universes |
$1369.00 |
PDF |
|
PDF DWG |
| 123 |
One input, three output fully isolated splitter |
$741.00 |
PDF |
|
PDF DWG |
| 123-JBOX |
One input, three output fully isolated splitter in a NEMA 1junction box |
$741.00 |
PDF |
N/A |
PDF DWG |
| 124 |
One input, four output fully isolated DMX splitter with RDM functionality |
$503.00 |
PDF |
|
N/A |
| 124-TB-JBOX |
One input, four output fully isolated DMX splitter with RDM functionality, terminal block connectors in a junction box |
$700.00 |
PDF |
|
N/A |
| 125 |
One input, five output fully isolated splitter |
$1058.00 |
PDF |
|
PDF DWG |
| 125-JBOX |
One input, five output fully isolated splitter in a NEMA 1 junction box |
$1058.00 |
PDF |
N/A |
PDF |
| 125EE |
Enhanced version of above [What is enhanced?] |
$1369.00 |
PDF |
|
PDF DWG |
| 125EE-5-FT |
Feed thru version of above |
$1440.00 |
PDF |
|
PDF DWG |
| 125EE-WALL |
Add -WALL to P/N for flanged wall mount enclosure for 125EE |
no charge |
HTML |
|
PDF DWG |
| 127 (Formally BIDI8) |
One input, seven output fully isolated DMX splitter with RDM functionality |
$1915.00 |
PDF |
|
PDF DWG |
| 127-JBOX |
One input, seven output fully isolated DMX splitter with RDM functionality in a NEMA 1 box |
$1915.00 |
PDF |
|
PDF DWG |
| 1211 |
One input, eleven output fully isolated splitter |
$2190.00 |
PDF |
|
PDF DWG |
| 1211-JBOX |
One input, eleven output fully isolated splitter in a NEMA 1 junction box |
$2190.00 |
PDF |
N/A |
PDF DWG |
| 1212-DIN |
One input, twelve output DMX/RDM DIN rail mounted splitter |
$1128.00 |
PDF |
N/A |
|
| 1212-DIN-JBOX |
One input, twelve output DMX/RDM DIN rail mounted splitter in a NEMA 1 junction box |
$1222.00 |
PDF |
N/A |
|
| 1212-DIN-JBOX-PS |
One input, twelve output DMX/RDM DIN rail mounted splitter in a NEMA 1 junction box with power supply included |
$1315.00 |
PDF |
N/A |
|
| PSDIN-30W-24V |
24V DC transformer for 1212-DIN or 1212-DIN-JBOX |
$60.00 |
N/A |
|
N/A |
| Add -3, -5, or -TB to end of part number for 3 pin XLR, 5 pin XLR, or Terminal Block, respectively.
Mixed XLR connectors are available at no extra charge from the factory. (Not applicable for model 124) |
Top
| DMX512 ROTOR-ROUTERS |
| ROTOR-ROUTER is the name of our electronic patch bay that allows multiple DMX512 input locations to be routed
to multiple DMX512 output locations. Up to twelve input locations can be 'patched' to an unlimited number of output locations
via twelve position rotary switches (one switch per output). For small distribution needs, a single module with mixed inputs
and outputs (no additional charge) may be all that is needed. |
| Model: |
Description |
MSRP |
DATA SHEET |
PHOTOS |
DRAWINGS |
| RR |
Available in many configurations. Priced per 12 connections |
$3446.00 |
PDF |
|
PDF DWG |
| RR-RIBBON |
Ribbon cable, priced per connector |
$10.00 |
N/A |
N/A |
N/A |
Top
| DMX A/B SWITCH BOXES |
| Switch Boxes are passive (no power required) mechanical switches typically used to select between two consoles or two console locations. |
| Model: |
Description |
MSRP |
DATA SHEET |
PHOTOS |
DRAWINGS |
| SW1 |
Single universe A/B switch box |
$242.00 |
PDF |
|
PDF DWG |
| SW2 |
Two universe A/B switch box |
$370.00 |
PDF |
|
PDF DWG |
| SW3 |
Three universe A/B switch box |
$682.00 |
PDF |
|
|
| SW4-5 |
Four universe A/B switch box, 5 pin XLR |
$875.00 |
PDF |
|
PDF DWG |
| SW4-TB |
Four universe A/B switch box, terminal block |
$875.00 |
PDF |
|
PDF DWG |
| SW5 + |
More than four universes |
CALL |
PDF |
|
|
|
A/B/C or A/B/C/D |
CALL |
PDF |
|
|
Top
| DMX512 COMBINE UNITS |
|
Mergers (combiners) take DMX512 signals from multiple sources and merge them to a single output. These units
can be used to accept inputs from multiple control locations such as input jacks throughout a ballroom or from primary and
backup consoles. The most common combination algorithm is Highest Takes Precedence (HTP), where the output for each DMX channel
is the highest level on any input for that channel. Other combination methods (priority mode, take control, etc.) are also available.
|
| Model: |
Description |
MSRP |
DATA SHEET |
PHOTOS |
DRAWINGS |
| 221E |
Fully isolated and protected two input merge |
$1645.00 |
PDF |
|
PDF DWG |
| 321E |
Three input version of above |
$2628.00 |
PDF |
|
|
| 421E |
Four input version of above |
$3645.00 |
PDF |
|
|
| 521E |
Five input version of above |
$4605.00 |
PDF |
|
|
| 621E |
Six input version of above |
$5527.00 |
PDF |
|
PDF DWG |
| -WALL |
Add -WALL to P/N for flanged wall mount enclosure for models 221E-621E |
no charge |
HTML |
|
PDF DWG |
| -WALL-JBOX |
Add -WALL-JBOX to part number to install -WALL version into a NEMA 1 junction box |
added charge |
HTML |
N/A |
DWG |
Top
| DMX512 INTERFACE PRODUCTS |
| Model: |
Description |
MSRP |
DATA SHEET |
PHOTOS |
DRAWINGS |
| DMX1AMXE |
Single AMX192 output port for up to 192 dimmers |
$1777.00 |
PDF |
|
PDF DWG |
DMX to analog converters produce analog control signals from the DMX512 levels. Doug Fleenor
Design's analog signals meet the ANSI E1.3 standard (0 to 10V Analog Control Specification). Analog signals from these
converters are typically used to control analog (0-10V) dimmers, LED indicators, fog machines, and anything else that has
a 0-10V analog control input.
DMX to AMX converters allow control of dimming systems based on the AMX192 control standard via DMX512. Doug Fleenor
Design's converters are very fast and very reliable for demanding applications. Conversion to/from Colortran's CMX protocol is
accomplished using our DMX merge products. Units with any number of DMX512 inputs and AMX192 outputs can be manufactured on a per
order basis. Please call.
|
|
| DMX96ANL |
96 0-10V analog outputs on (4) DB-25 connectors |
$2317.00 |
PDF |
|
PDF DWG |
| DMX12ANL |
12 channel DMX512 to analog 0-10V interface |
$964.00 |
PDF |
N/A |
PDF DWG |
| DMX12ANL-DIN |
12 channel DMX512 to analog 0-10V interface, DIN rail mounted |
$964.00 |
PDF |
N/A |
N/A |
| DMX12ANL-DIN-JBOX |
12 channel DMX512 to analog 0-10V interface, DIN rail mounted in a NEMA 1 junction box |
$1056.00 |
PDF |
N/A |
N/A |
| DMX12ANL-DIN-JBOX-PS |
12 channel DMX512 to analog 0-10V interface, DIN rail mounted in a NEMA 1 junction box with power supply included |
$1152.00 |
PDF |
N/A |
N/A |
| The analog to DMX512 converter accepts discrete analog control voltages and generates a DMX512
control signal based on these inputs. The input analog control voltage is usually zero-to-ten volts, but units can be modified
to accept virtually any control range. |
|
| ANL2DMX |
48 0-10V analog inputs on (2) DB-25 connectors, DMX512 output on (1) 5pin XLR |
$2317.00 |
N/A |
|
N/A |
| Relay packs use the DMX512 signal levels to control on/off functions. Doug Fleenor
Design makes two types of relay packs: line voltage and low voltage. Line voltage packs switch the incoming AC power to AC
receptacles. Low voltage packs provide contact closures on XLR connectors. Some manufacturers' relay packs use solid-state
devices. Doug Fleenor Design's use mechanical (air-gap) relays. Mechanical relays are uncomplicated, work with most any
voltage, do not leak current, have consistently low contact resistance, work on AC or DC circuits, and do not get hot. The
primary disadvantage of mechanical relays is their finite life span (typically more than 100,000 operations). |
|
|
| DMX1REL20A |
Line voltage output, single channel, 20 amps |
$643.00 |
PDF |
|
PDF DWG |
| DMX1REL20A-2POLE |
Line voltage output, single channel, 20 amps, 208-240VAC |
$688.00 |
PDF |
|
|
| DMX2REL5A |
Low voltage contact closures, two channel, 5 amps/chan. |
$643.00 |
N/A |
|
PDF DWG |
| DMX6REL1A |
Low voltage contact closures, six channel, 1 amp/chan. |
$964.00 |
N/A |
|
PDF DWG |
| DMX6REL15A |
Line voltage output, six channel, 15 amps/chan. 15 amps total |
$830.00 |
PDF |
|
PDF DWG |
| DMX6REL30A |
Line voltage output, six channel, 15 amps/chan. 15 amps total |
$980.00 |
PDF |
|
PDF DWG |
| DMX96OC |
96 open collector NPN outputs on (4) DB-25 connectors |
$2075.00 |
PDF |
|
PDF DWG |
| Assembled and tested boards with one to twenty-four relays are available for OEM applications. Please call. |
| DMXDECELERATORII |
DMX Timing Decelerator, Version 2 |
$250.00 |
PDF |
|
PDF |
| 2322DMX |
RS-232 to DMX |
$1777.00 |
PDF |
|
PDF DWG |
| DMX2iPLAY |
DMX to iPlayer 2 |
$1777.00 |
PDF |
|
PDF DWG |
| DMX2DALI |
DMX512 to DALI 128 channel |
$964.00 |
PDF |
|
PDF DWG |
| DMX2MPX |
DMX512 to NSI Microplex 64 or 128 channel |
$964.00 |
PDF |
|
PDF DWG |
| DININTR |
1 open collector output NPN or PNP. DIN rail mounted |
$445.00 |
PDF |
N/A |
N/A |
| GPI |
General Purpose Interface. Up to two outputs. |
$296.00 |
PDF |
|
N/A |
| ALARMINTERFACE |
Allows an emergency system to trigger a pre-recorded emergency DMX512 backup look. |
$964.00 |
PDF |
N/A |
N/A |
| ALARMINTERFACE-DIN |
Allows an emergency system to trigger a pre-recorded emergency DMX512 backup look. DIN-rail mounted |
$964.00 |
PDF |
N/A |
N/A |
Top
| CONSOLES |
| DMX512 control consoles generate the DMX512 control signal based on operator input. Doug Fleenor Design
debuted the Apathy console in 1999. In 2003 we introduced the Preset 10 consoles. The Apathy is a single channel console
that defaults to all DMX512 levels being patched to its single knob. A user hostile interface allows the Apathy to control
a single channel, however. The Preset 10 is a snapshot console that captures up to ten static looks and plays them back at
the touch of a button. |
| Model: |
Description |
MSRP |
DATA SHEET |
PHOTOS |
DRAWINGS |
| APATHY |
Single channel console |
$296.00 |
PDF |
|
PDF DWG |
| PRE8-A |
8 scene preset, sliding intensity control, three-gang architectural |
$1485.00 |
PDF |
|
N/A |
| PRE8-P |
8 scene preset, sliding intensity control, pelican box enclosure |
$1645.00 |
PDF |
|
N/A |
| PRE8-D |
8 scene preset, sliding intensity control, solid milled aluminum chassis |
$1645.00 |
PDF |
|
N/A |
| PRE10-A |
10 scene preset, single gang architectural |
$788.00 |
PDF |
|
PDF DWG |
| PRE10-A-POPO |
10 scene preset, single gang architectural, with push on, push off software |
$788.00 |
PDF |
|
PDF DWG |
| PRE10-A-WHT |
10 scene preset, single gang architectural, white faceplate and buttons |
$820.00 |
PDF |
|
PDF DWG |
| PRE10-SPACER |
Optional spacer for the model PRE10-A; for use with most backboxes, black |
$31.00 |
N/A |
|
N/A |
| PRE10-SPACER-WHT |
Optional spacer for the model PRE10-A; for use with most backboxes, white |
$33.00 |
N/A |
|
N/A |
| PRE10-P |
10 scene preset, portable |
$825.00 |
PDF |
|
PDF DWG |
| PRE10-P-POPO |
10 scene preset, portable, with push on, push off software |
$825.00 |
PDF |
|
PDF DWG |
| PRE10-A2 |
10 scene preset, two gang architectural, with pile on input |
$1365.00 |
PDF |
|
DWG |
| PRE10QUATTRO |
10 scene preset, two gang architectural, four universe |
$1155.00 |
PDF |
|
N/A |
| PRE12-BLK |
12 scene preset, single gang architectural, black |
P.O.A. |
PDF |
|
N/A |
| PRE12-WHT |
12 scene preset, single gang architectural, white |
P.O.A. |
PDF |
|
N/A |
| PRE18-BLK |
18 scene preset, two gang architectural, black |
P.O.A. |
PDF |
|
N/A |
| PRE18-WHT |
18 scene preset, two gang architectural, white |
P.O.A. |
PDF |
|
N/A |
| ES2 |
Two button architectural entry station. Single gang |
$788.00 |
PDF |
|
PDF DWG |
| ES2-WHT |
Two button architectural entry station. Single gang. White faceplate and buttons |
$820.00 |
PDF |
|
PDF DWG |
| RERUN-A |
Architectural lighting control station capable of storing up to ten 40-minute shows. |
$1697.00 |
PDF |
|
PDF DWG |
| RERUN-P |
Portable lighting control station capable of storing up to ten 40-minute shows. |
$1777.00 |
PDF |
|
N/A |
| RERUN-R1 |
Rack mount 1 universe lighting control station capable of storing up to ten 40-minute shows. |
$1830.00 |
PDF |
|
|
| RERUN-R2 |
Rack mount 2 universe lighting control station capable of storing up to ten 40-minute shows |
$2530.00 |
PDF |
|
|
| RERUN-R3 |
Rack mount 3 universe lighting control station capable of storing up to ten 40-minute shows |
$3300.00 |
PDF |
|
|
| RERUN-R4 |
Rack mount 4 universe lighting control station capable of storing up to ten 40-minute shows |
$4070.00 |
PDF |
|
PDF DWG |
| XFMR |
Transformer for PRE10-A, PRE10-A-POPO, RERUN-A, ES2, or ColorWheel |
$33.00 |
N/A |
|
N/A |
| ColorWheel |
A simple wall-mounted device designed to operate DMX512 based LED lighting fixtures. |
$495.00 |
N/A |
|
N/A |
Top
MARCONI WIRELESS DMX SYSTEM  |
|
The Marconi wireless system from Doug Fleenor Design allows DMX512 distribution where cabling is
not practical. Doug Fleenor believes cable is more reliable than wireless, but recognizes the advantages of
wireless systems such as quicker setup, building top to building top (or cross river) communications, fewer wires
to tape down, as a backup to a cable link, for troubleshooting, for focusing before the FOH cables are installed,
and so on. |
| Model: |
Description |
MSRP |
DATA SHEET |
PHOTOS |
DRAWINGS |
| Marconi TX |
Wireless DMX transmitter |
$1054.00 |
PDF |
|
N/A |
| Marconi SP |
Wireless DMX receiver with three output isolated splitter |
$1233.00 |
PDF |
|
N/A |
| Marconi LV |
Wireless DMX receiver for LED300 or scrollers |
$920.00 |
PDF |
|
N/A |
| Marconi LV PSU |
Optional external power supply for Marconi LV |
$47.00 |
N/A |
|
N/A |
Top
| POWER SUPPLIES |
| Model: |
Description |
MSRP |
DATA SHEET |
PHOTOS |
DRAWINGS |
| LED600 |
600w LED power supply, 12 outputs |
$2851.00 |
PDF |
|
N/A |
| LED300 |
300w LED power supply, 6 outputs |
$2240.00 |
PDF |
|
N/A |
| LED100 |
100w LED battery power supply w/ wireless DMX receiver |
$1871.00 |
PDF |
|
N/A |
Top
| WALL PLATES |
| Wall plates can be either passive or active. Our passive wall plates incorporate an XLR connector
mounted to a single gang, machined aluminum, black anodized, engraved wall plate with screw terminals for the
in-wall wiring. These passive wall plates would then be wired back to a rack or wall mounted splitter, merger, or
Rotor-Router. Active wall plates include buffer circuitry which allows more advanced distribution methods. |
| Model: |
Description |
MSRP |
DATA SHEET |
PHOTOS |
DRAWINGS |
| DFDNET |
Buffered Female XLR single gang plate |
$303.00 |
HTML |
|
PDF DWG |
| DFDNET-PS |
Power supply for DFDNET |
CALL |
N/A |
N/A |
N/A |
| WP-I |
Male XLR single gang plate |
$150.00 |
HTML |
|
PDF DWG |
| WP-O |
Female XLR single gang plate |
$150.00 |
HTML |
|
PDF DWG |
| WP-RJ |
RJ-45 single gang plate |
$150.00 |
HTML |
|
PDF DWG |
| Add -3 or -5 to end of part number for 3 pin XLR or 5 pin XLR. |
Top
| TEST TOOLS & ACCESSORIES |
| Model: |
Description |
MSRP |
DATA SHEET |
PHOTOS |
DRAWINGS |
| GIZMO |
DMX512 Test Unit |
$1078.00 |
PDF |
|
N/A |
| RAD |
Remote Addressing Device |
$264.00 |
PDF |
|
N/A |
| DMXTSTR |
DMX512 Line tester |
$90.00 |
PDF |
|
N/A |
| TERM |
120 Ohm terminator with "happy" LED and spike suppression. 3 or 5 pin XLR connector |
$77.00 |
PDF |
|
N/A |
| T2 |
120 Ohm terminator 3 pin, 4 pin or 5 pin XLR connector |
$44.00 |
PDF |
|
N/A |
| T-45 |
120 Ohm terminator RJ-45 plug |
$10.00 |
N/A |
|
N/A |
| Add -3, -4, or -5 to end of part number for 3 pin XLR, 4 pin XLR, or 5 pin XLR respectively. |
Top
| DIMMERS |
| Our 8 channel dimmer is created especially for low power, high efficacy loads. |
| Model: |
Description |
MSRP |
DATA SHEET |
PHOTOS |
DRAWINGS |
| DMX8DIM |
Low power, high efficacy 8 channel dimmer. |
$936.00 |
PDF |
|
N/A |
| DMX12DIM-ELV |
Low power, high efficacy 12 channel dimmer. Grounded. Occupies 1U of rack space. |
$1497.00 |
PDF |
|
N/A |
| DMX24DIM |
Low power, high efficacy 24 channel rack mount dimmer. Ungrounded. Occupies 1U of rack space. |
$1871.00 |
PDF |
|
N/A |
| DMX24DIM-2U |
Low power, high efficacy 24 channel rack mount dimmer. Grounded. Occupies 2U of rack space. |
$1965.00 |
PDF |
|
N/A |
| Q.TRIAC-16A |
Replacement triac for DMX8DIM, DMX24DIM & DMX24DIM-2U. |
$7.00 |
N/A |
N/A |
N/A |
Top
| RACK KITS |
| Model: |
Description |
MSRP |
DATA SHEET |
PHOTOS |
DRAWINGS |
| RK6-1 |
Rack kit for a 121, 121D, 123, DMX2REL5A, DMX1REL20A, DMX2MPX, SW1, DMX1AMX |
$44.00 |
PDF |
N/A |
PDF DWG |
| RK8-1 |
Rack kit for a 125, 125EE, 221E - 621E, DMX2DALI, SW2, 2322DMX, DMX12ANL |
$44.00 |
PDF |
N/A |
PDF DWG |
| RK8-2 |
Rack kit for two 125EE, 221E - 621E |
$44.00 |
PDF |
N/A |
PDF DWG |
RK8-2-S |
Rack kit for two 125, 2322DMX, DMX2DALI, DMX12ANL, SW2 |
$60.00 |
PDF |
N/A |
PDF DWG |
| RK16-1 |
Rack kit for a 121Q, 1211, BIDI8, SW3, SW4, DMX6REL15A, DMX6REL30A, DMX96OC, NODE4, E2E |
$44.00 |
PDF |
N/A |
PDF DWG |
| RKT1-3 |
Rack kit for up to three DMX6REL1A |
$65.00 |
N/A |
N/A |
PDF DWG |
| RKB1-1 |
Rack kit for DMX96ANL |
$44.00 |
N/A |
N/A |
N/A |
| RK8-1FMC-5 |
Rack kit for 125 and 125EE with 5pin XLR front mount connectors |
$288.00 |
N/A |
N/A |
N/A |
| RK8-1FMC-5-FT |
Rack kit for 125 and 125EE with 5pin XLR front mount connectors and a feed thru connector |
$306.00 |
N/A |
N/A |
N/A |
| RK-WALL |
Kit for mounting any 6", 8", or 16" wide chassis to a flat surface. Kit comes with 4 L-brackets. |
$44.00 |
N/A |
N/A |
N/A |
Top
| Ethernet Products |
| Model: |
Description |
MSRP |
DATA SHEET |
PHOTOS |
DRAWINGS |
| E2E |
Ethernet to Ethernet interface |
$2246.00 |
PDF |
|
N/A |
| E1REL20A |
Single Channel sACN/ArtNet Controlled Relay |
$643.00 |
PDF |
|
N/A |
| E1REL20A-2POLE |
Single Channel sACN/ArtNet Controlled Relay, 2 Pole |
$688.00 |
PDF |
|
N/A |
| E8ANL-DIN |
8 Channel Ethernet to Analog 0-10V Interface |
$962.00 |
PDF |
|
N/A |
| E8ANL-DIN-JBOX |
8 Channel Ethernet to Analog 0-10V Interface, in a junction box |
$1056.00 |
PDF |
|
N/A |
| NODE1-A |
1 Port Ethernet Network to DMX Interface, architectural |
$968.00 |
PDF |
|
N/A |
| NODE1-P |
1 Port Ethernet Network to DMX Interface, portable |
$1000.00 |
PDF |
|
N/A |
| NODE2-A |
2 Port Ethernet Network to DMX Interface |
$1497.00 |
PDF |
N/A |
N/A |
| NODE4 |
4 Port Ethernet Network to DMX Interface |
$1497.00 |
PDF |
|
N/A |
| NODE16-RACKMOUNT |
16 Port Ethernet Network to DMX Interface, rackmount enclosure |
$2984.00 |
PDF |
|
N/A |
| NODE16-DIN |
16 Port Ethernet Network to DMX Interface on a DIN-rail |
$2122.00 |
PDF |
|
N/A |
| NODE DISCOVERY |
Network Discovery Application |
$0.00 |
N/A |
N/A |
N/A |
| PRE10ETHER-A |
10 Scene Ethernet Snapshot Controller |
$1155.00 |
PDF |
|
N/A |
| ES2ETHER |
2 Scene Ethernet Snapshot Controller |
$1124.00 |
PDF |
|
N/A |
|
